Modul-Compete 50 modular Signal tower Ø 50mm
Overview
Modul-Compete 50 modular Signal tower Ø 50mm Cost-optimised modular 50 mm Ø signal tower for classic 24V DC applications in industry Up to 5 positions possible
Product detail
- Cost-optimised modular 50 mm Ø signal tower
- for classic 24V DC applications in industry
- Up to 5 positions possible
- Low soiling due to flat-flush smooth exterior design
- Maximum product availability due to minimum number of articles (only 23 order numbers)
- LED multifunction and LED continuous light modules in 6 colours
- Efficient sound module selectable up to 95 dB – 8 tones
- Optimised ‘resilient’ bayonet system enables high stability, even without sealing rings
- five-pole M12 base with automatic contacting push-in system
- All common mounting types
Technical data
| Housing | Ø 50 mm, black (RAL 9005) |
| Lens | Polycarbonate, ribbed inside |
| Type of mounting | horizontal, vertical, Tube mounting or NPT 1/2″ |
| Beacon type | LED steady light, flashing light, strobe light and double strobe light |
| Light source | LEDs |
| Tone | see tone table |
| Volume | 95- dB |
| Duty cycle | 100 % |
| Service life | Light source: 100.000 h |
| Number of possible modules | max. 5 |
| Operating temperature | -30 °C / +60 °C |
| Degree of protection | IP65 & UL Type 4/4x/13 |
| Impact resistance | IK07 |
| Weight (modules) | 26-149 g |
