MOREK Gel filled underground connections’ joints Gel joints Break series is suitable to guarantee insulation of low voltage main and shunted, single-pole and multi-pole connections ranging from 0,6/1 kV. The list of products is made up of a series for main connections and a series for shunted connections. The first series allows single-pole and multi-pole connections with max. section respectively of 1×185 mm² and 4×25 mm²; the second series allows single-pole and multi-pole shunted connections with max. section respectively of 1×120 mm² e 4×10 mm².
MOREK Universal terminal blocks for copper and aluminium Universal terminals OTL are designed for copper and aluminium conductors. The terminals are suitable for all types of copper or aluminium conductors with cross section up to 240 mm². Multiple copper wires can be placed to the OTL terminal blocks according to the respective terminal type (see Table of universal terminals OTL wiring connectivity below). IP protection class for OTL terminals is IP20.
Distribution blocks OJL are intended for distributing conductors with larger cross-section to several smaller ones. These blocks are provided in 6 standard designs with a nominal connecting crosssection of 70 mm² Al/Cu (6 outputs for copper cable), 120 mm² Al/Cu (11 outputs for copper cable) and 240 mm² Al/Cu (7 outputs for copper cable). AF and AFS models are designed for connecting (input) of flxible busbars 10 x 25 mm or several other bars of 1 x 25 mm. MOREK
